archsynth ai master prompt dfma locked supplier referenced shop drawing page 01 authority 1 authoritative source control non negotiable all geometry proportions junctions and finishes must be interpreted strictly from shop drawing j01 001 page 01 do not infer substitute stylise or approximate materials colours or textures if a finish is not explicitly listed on page 01 it must not be introduced 2 geometry fabrication logic model joinery exactly as a manufacturable cabinet assembly not conceptual furniture respect real world tolerances panel thicknesses shadow gaps and reveals all curved elements bench kick end panels must follow true radii as drawn not smoothed approximations doors drawer fronts kick faces and shrouds must be visually distinct as separate fabricated components no razor sharp edges apply micro arris softened edges consistent with laminated mdf and stone fabrication 3 material lock page 01 finishes only use the following verbatim material definitions these must be treated as absolute truth primary joinery doors drawer fronts panels wd 01 material mdf thickness 18 3mm finish soft walnut ravine edge matching 1mm abs supplier polytec texture authority must be referenced https www polytec com au colour soft walnut ravine critical controls grain must run vertically on doors and drawer fronts unless geometry forces otherwise ravine texture must show deep linear grain relief not flat walnut colour must remain warm light brown with subtle contrast no red or dark walnut bias internal carcase lp 01 material mdf thickness 18 3mm 25 3mm where noted finish white melamine matt edge matching 1mm abs supplier polytec rules matt white only zero gloss internals visible only where doors are open or recessed benchtop splashback st 00 material taj mahal quartzite thickness 20mm finish honed supplier marblous group controls honed low sheen soft reflection not polished veining must be subtle warm linear not dramatic marble contrast veins should flow parallel to long bench axis metal components plates shroud elements mt 00 material metal finish dark brown bronze coating clear satin thickness 1 6mm supplier astor metal finishes controls satin metallic reflection only no mirror gloss colour sits between bronze and dark brass warm not blackened curved substrate where applicable bply4 5 material bendy ply thickness 4 5mm role substrate only finish painted laminated to match adjacent specified finishes 4 hardware appliance visual intent appliances fisher paykel miele insinkerator franke must read as real products but remain secondary to joinery handles o hd 07 blunt dark brass o hd 15 suave dark brass brass must remain muted satin never yellow or mirror polished 5 lighting render control use a neutral daylight interior hdri 5000k avoid dramatic contrast or marketing mood lighting timber grain stone honed finish and satin metals must read clearly under soft diffuse light shadows should be soft consistent with residential interiors 6 camera composition lens equivalent 35 45mm viewpoint eye level or slightly above bench height framing must clearly show o curved end geometry o transition between wd 01 timber and st 00 stone o relationship between doors drawers kick and bench 7 strict exclusions no alternative walnut tones no generic wood texture no polished stone no stylised exaggeration of grain or veining no colour grading beyond neutral photographic balance
