use all provided architectural drawings floor plans foundation site plans roof plans side elevations front and rear elevations as the primary and authoritative source of truth create a premium class ultra photorealistic 3d exterior visualization of the left outer side facade of the modern two storey semi detached duplex house camera and composition show the house directly from the left side the camera must look straight and perpendicularly at the left exterior wall this must not be a corner view three quarter view or diagonal perspective camera position centered in relation to the main left side facade camera height approximately 1 60 1 70 m above the finished exterior ground level camera sensor perfectly level all vertical architectural lines perfectly straight no wide angle distortion lens approximately 55 70 mm full frame equivalent minimal perspective distortion clean direct elevation like architectural composition the entire left side facade and full roof height must fit naturally inside the frame only a very narrow part of the front or rear facade return may be visible if physically necessary to explain the building depth but the image must visually read as a straight on left side facade visualization duplex geometry and offset this is one semi detached duplex building composed of two connected house units critical geometry both houses share one common wall there is no physical gap between the two units the right side house volume remains in the forward alignment the left side house volume is shifted approximately 2 25 m deeper into the plot the units are not aligned in one completely flat line the offset is introduced to provide additional privacy preserve this offset accurately in the 3d model do not incorrectly separate the houses into two freestanding buildings do not create a visible open slot or passage between the houses even in the direct left side view the front and rear edges roof intersections facade returns shadows and terrace relationship must remain consistent with the correct 2 25 m offset building geometry preserve the exact architectural geometry shown in the drawings two storey semi detached duplex two equal connected gabled house volumes shared central wall correct overall height correct wall proportions correct 40 degree main roof slopes correct roof ridge heights correct roof overhangs correct central roof connection and valley saddle geometry correct front to rear building depth correct relationship between the first floor upper floor roof entrance canopy and rear terrace structure do not simplify the architecture into one generic rectangular house do not introduce flat roofs dormers projecting balconies balcony slabs garages carports pergolas extra canopies additional decorative structures dark metal upper floor and roof both duplex units must use exactly the same dark graphite metal finish material standing seam classic type metal cladding vertical standing seams on all upper floor facade areas realistic standing seams running according to the roof slope on roof surfaces matte or extremely low gloss finish refined premium slightly textured coated metal official project color rr 23 dark grey ai visual color reference primary range 3f4141 to 484a49 use this same rr 23 dark graphite finish for both roofs both upper floor exterior walls gable walls roof edge flashings fascia and metal trim rain gutters downpipes snow guards entrance canopy metal cladding underside and edge of the upper floor cantilever where metal finishing is required the metal must not look glossy metallic silver blue absolute black plastic randomly patterned the standing seam rhythm must be consistent precise and realistically scaled ground floor clinker facade the entire visible ground floor facade must use elongated horizontal clinker tiles according to the project material appearance refined light warm grey greige clinker elongated horizontal format matte mineral surface subtle natural tonal variation slim joints close to the tile color high end contemporary architectural finish primary ai color b5afa5 natural tile variation darker tiles approximately a59f96 lighter tiles approximately c3bdb3 the clinker must not look white yellow orange red dark brown rustic heavily weathered like rough natural stone like large concrete slabs maintain a refined horizontal texture and accurate corner detailing windows doors frames and flashings all exterior window and door frames must use a premium near black matte finish official recommended color ral 9005 ai visual color approximately 111212 to 171818 use this finish consistently for window frames exterior door frames mullions transoms exterior window sills narrow metal flashings visible handles and hardware glazing perimeter profiles profiles must appear slim contemporary matte precisely constructed dark but still visibly detailed in daylight do not use white frames light grey frames glossy black plastic thick generic pvc profiles left side facade openings reproduce the exact number location proportions and dimensions of all windows and doors visible on the left side facade according to the provided side elevation and floor plan the drawings are the source of truth carefully preserve the narrow ground floor window the medium width ground floor window the large ground floor glazed opening window group the exact spacing of clinker wall sections between openings the correct sill heights the correct head heights the exact relation of windows to the floor levels the rooflight velux position visible on this roof plane the exact entrance canopy location if visible on this side all exterior wall projections and recesses do not invent additional windows remove windows move windows enlarge windows for aesthetic reasons make the facade symmetrical if the drawings are not symmetrical replace the actual opening arrangement with a generic design rooflight preserve the exact velux rooflight indicated on the side elevation and roof plan rooflight velux type approximate project size 1180 940 mm integrated flush into the standing seam metal roof dark grey black exterior frame and flashing realistic glass reflection not excessively raised above the roof do not add additional rooflights to this visible roof plane unless they are clearly shown in the project drawings entrance canopy where the entrance canopy parapet is visible on this side facade reproduce it accurately the canopy must be thin horizontal minimalist cantilevered without decorative support columns finished on the top and front edge in dark graphite rr 23 metal approximately aligned with the project levels visually refined and structurally realistic do not make it into a pitched roof a wooden canopy a pergola a thick concrete slab a canopy supported by decorative posts wood accent use smoked walnut toned thermally modified timber only in the project defined entrance portal areas if any timber is visible from this side view recommended material thermally modified ash or thermally modified pine vertical narrow boards refined smoked walnut oil stain matte finish subtle natural grain ai color range 5b4030 to 72523d do not use orange oak yellow pine red mahogany glossy varnish timber across the entire side facade timber on the upper gable timber on the terrace columns timber must remain a small controlled premium accent plinth use a low plastered dark grey plinth official color ral 7031 blue grey ai visual reference approximately 4b5053 the plinth must be matte smooth visually low restrained partially integrated with the surrounding gravel strip do not create a high basement wall a black stone base a decorative stone plinth a strongly contrasting horizontal band rear terrace geometry visible from the side the rear terrace construction is a critical part of the side facade and must remain geometrically correct each house has its own terrace for the terrace belonging to the visible side unit approximately half of the terrace is located underneath the second floor house volume this creates a covered terrace zone below the upper floor approximately the other half of the terrace projects beyond the upper floor volume and remains completely open to the sky the covered and uncovered parts form one continuous terrace the terrace is not fully covered the terrace is not fully open the covering must be created only by the actual second floor building volume do not add a pergola an independent roof a glass canopy a fabric awning a separate terrace structure terrace outer corner column at the external outer corner of the terrace place the required structural support column exactly as shown in the plan the column must stand at the outer corner of the covered terrace zone extend vertically from the terrace deck to the underside of the second floor visibly support the upper floor volume be structurally solid and believable be located exactly at the corner not in the middle of the terrace clearly define the covered terrace area remain visible and unobstructed recommended column finish the same light warm grey clinker as the ground floor facade base color b5afa5 natural variation a59f96 to c3bdb3 matching joints and tile format do not remove the column replace it with a thin steel post clad it in wood move it inward hide it behind furniture or landscaping side passage into the terrace preserve the open side entrance passage between the exterior terrace column and the house wall exactly as shown in the plan the passage must remain completely open clearly allow pedestrian access from the side yard to the terrace not be closed by a wall not be filled with glazing not be blocked by plants not be blocked by furniture visually explain the architectural relationship between the column cantilevered second floor and terrace this side passage is an essential design feature and must be clearly readable in the direct side view terrace doors and rear glazing where terrace doors or rear facade glazing are visible from the side keep their dimensions frame divisions positions and colors faithful to the plans and elevations do not invent generic sliding doors or change their placement second floor balcony doors and frame mounted glass guards where a second floor balcony door french balcony opening is visible from this side or near the rear facade return reproduce the glass safety guard accurately for each relevant balcony door install one separate clear frameless glass safety guard the safety glass must be fixed directly to the outer face of the balcony door frame the guard must not be fixed to a projecting slab there must be no projecting balcony floor the width of the glass guard must be exactly the width of that individual balcony door only the glass guard must not extend over adjacent fixed glazing the guard should cover approximately the lower half of the balcony door opening use clear tempered safety glass use minimal discreet point fixings or frame mounted connectors no vertical posts no heavy metal frame no full width railing no large top handrail it must visually read as a french balcony safety barrier mounted directly onto the dark balcony door frame terrace decking use premium thermally modified timber terrace boards recommended material thermally modified ash or premium thermally modified pine long straight boards concealed fixing narrow realistic gaps matte oiled finish both terraces identical in material and color ai terrace color 80664f to 967a61 the terrace should be slightly lighter than the entrance smoked walnut timber do not use orange decking bright yellow decking grey plastic composite glossy varnished boards rustic uneven planks paving and walkways where exterior paving or pedestrian access is visible use premium warm medium grey concrete paving recommended ai color 777671 to 85837d recommended appearance matte concrete clean rectangular format approximately 600 300 mm or similar contemporary proportion precise linear installation restrained tonal variation clean edges do not use red pavers multicolored cobblestones glossy stone rustic irregular paving bright white slabs gravel strip use a narrow dark grey gravel drainage strip around the building plinth material fine to medium basalt or granite gravel realistic size approximately 8 16 mm neat border between facade paving and lawn ai color 555653 to 656660 do not use white decorative stones multicolored river gravel oversized rocks glass appearance all standard windows and glazed doors must use realistic neutral clear architectural glass glass characteristics neutral slightly grey realistic reflections of sky trees and surroundings partial transparency subtle view into the interior no strong blue commercial tint no fully black opaque windows no mirror like office facade effect matte opaque glass sections where shown in the project neutral light to medium grey satin finish clearly different from metal cladding no blue or green tint glass safety guards clear tempered glass nearly frameless subtle edge thickness minimal attachments exterior lighting if exterior light fixtures are visible use small minimalist black architectural fixtures near black ral 9005 finish discreet recessed lighting below the entrance canopy or covered terrace zone light temperature 2700 3000 k warm white do not add decorative lanterns visible led strips across the facade cold blue lighting excessive uplighting landscape create a premium but restrained residential side yard environment use well maintained natural lawn a few subtle ornamental grasses limited refined shrubs natural mature trees in the background clean side walkway calm northern european residential atmosphere do not hide the facade behind vegetation hide windows hide the terrace column block the side terrace passage add dense flower beds create a tropical garden add swimming pools hot tubs or outdoor kitchens lighting and mood use bright natural daylight or soft lightly overcast daylight preferred atmosphere refined northern european daylight calm luxurious contemporary realistic premium real estate developer quality use soft directional light that clearly reveals the vertical standing seam texture the horizontal clinker texture the correct facade depth the roof geometry the terrace column the open terrace side passage the difference between covered and uncovered terrace zones avoid harsh midday contrast dramatic sunset strong orange lighting dark stormy weather exaggerated cinematic effects rendering quality ultra photorealistic architectural cgi premium real estate developer presentation quality use physically realistic materials accurate construction detailing realistic wall and roof thickness correct junctions realistic reflections natural material roughness accurate shadows subtle interior depth high resolution textures natural proportions clean professional composition important restrictions do not show the facade from a corner do not use a three quarter view do not distort the side wall do not use a wide angle lens do not align both duplex units in one flat plane do not remove the 2 25 m offset do not create a gap between the houses do not make one house light and the other dark both houses must use the same rr 23 dark graphite metal do not alter the roof geometry do not add extra rooflights do not remove the project rooflight do not invent extra windows do not move or resize the side facade windows do not use white window frames do not use glossy black metal do not use orange timber do not make the terrace fully open do not make the terrace fully covered do not add a pergola do not add a separate terrace roof do not remove the terrace outer corner column do not replace the column with a thin metal post do not close the side passage into the terrace do not block the terrace passage with furniture or plants do not create a projecting second floor balcony do not create a balcony slab do not create full width balcony railings do not widen the glass safety guard beyond its balcony door frame do not attach the glass guard to the wall it must be fixed directly to the balcony door frame do not add garages carports decorative roof structures or unnecessary luxury features do not make the house generic rustic traditional cartoon like or low quality
