interior elevation of a contemporary multi use hospitality space first floor the plan shows a large open plan room with a curved terrace balcony extension on the left side featuring rows of bistro chairs main interior includes loose round dining tables with chairs clustered in groups a central bar service counter at the south end lounge seating areas with sofas and armchairs toward the west wall and a reception or display zone with oval tables toward the north staircase core and wc block in the upper centre organic wavy wall detail on the right east perimeter draw the section a a elevation east west cut as marked on plan showing interior wall heights ceiling line the curved balcony facade on the left fenestration and furniture in section and elevation black and white technical drawing style clean line weights with graphic scale bar no dimensions scale 1 50
