convert this hand drawn sketch into a clean architectural elevation drawing black lines on white background cad style no shading no shadows no colors maintain proportions unit is divided into 2 sections left section tall closet width 20 inches 1 3 of total width full height floor to ceiling 96 inches has 2 stacked doors one above the other upper door starts at 56 75 from floor ends at 90 5 height 33 75 inches tall lower door starts at 2 5 from floor ends at 56 75 height 54 25 inches tall both doors have shaker panel inner rectangle inset 1 5 bar pull handle on right side of each door right section open mudroom width 40 inches 2 3 of total width divided into 4 zones from top to bottom zone 1 upper cubbies top height from 66 to 92 26 inches tall 2x2 grid 4 open compartments left column width 17 75 right column width 17 75 top row height 10 bottom row height 11 5 face frame border 1 5 all around zone 2 hook board height from 56 75 to 66 9 25 inches tall full width 40 inches 4 coat hooks evenly spaced board is recessed mounted to back wall zone 3 batten zone open wall space height from 18 to 56 75 38 75 inches tall 3 vertical wood strips on back wall 1 horizontal wood strip at bottom at 18 height otherwise completely open you can see the wall zone 4 bench bottom height from 16 5 to 18 1 5 inches thick seat depth 19 inches extends 1 beyond legs 2 box legs only left leg and right leg each leg 1 5 wide 18 deep completely open to floor no panels below bench crown molding very top height from 92 to 96 4 inches tall runs full width 60 inches has decorative profile stepped shape left end flush to wall right end shows return total dimensions total width 60 inches 5 feet total height 96 inches 8 feet closet depth 20 inches cubbies depth 12 inches shallower than closet by 8 inches bench depth 19 inches
