task redesign the provided floor plan into a dental clinic using the uploaded drawing as a fixed architectural shell the result must be a precise technical floor plan not a conceptual variation general rules absolute constraints the input drawing is a fixed base do not modify exterior perimeter facade outline curved geometry structural load bearing walls hatched walls only internal partitions may be added or adjusted keep existing wall thicknesses and drafting language maintain similar room proportions unless adjustment is required for function drawing style mandatory monochrome black white same line weights hierarchy same hatching for structural walls same door window symbols same furniture graphic style dental chairs etc match the visual style of the reference exactly exterior openings strict no interpretation curved facade left circular zone there are 3 existing windows the central window must be converted into the only entrance door the currently marked entrance must be removed and replaced with a window after redesign total openings remain the same only one entrance exists in the entire building straight facade bottom right there are 2 windows these must belong exclusively to the main treatment room prohibited adding openings removing openings moving openings creating secondary entrances functional zoning strict placement 1 reception administration entry zone use 100 of the circular room this space must include reception desk facing entrance waiting area seating this is the only public entry space 2 main treatment room primary clinical space must be placed exactly inside the marked rectangular zone in the reference must extend along the entire facade with the two windows area minimum 21 m target 21 28 m layout requirements 2 dental units maintain clear working zones around each chair include operator stools assistant access cabinetry or sink wall internal side 3 support rooms strict linear block must be placed only along the upper wall opposite the windows must form a continuous row order right left no deviation toilet staff room sterilization room compressor technical room this order is fixed and cannot be changed corridor mandatory organizing element create one straight corridor between treatment room bottom support rooms top corridor requirements width 1 4 1 6 m must run horizontally across the plan must connect reception corridor corridor treatment room corridor each support room individually access rules each support room has its own door from corridor treatment room has door from corridor only adjacency rule sterilization room must be directly adjacent or closest possible to treatment room spatial logic must be clearly readable the plan must strictly follow this zoning sequence curved front zone reception only entrance middle band corridor facade with windows treatment room opposite wall linear support rooms layout must be linear and layered not central not radial not scattered strict prohibitions zero tolerance arshin must not change outer shell in any way move structural hatched walls add more than one entrance place any support room near facade windows break the linear order of rooms distribute rooms across different zones create alternative interpretations or redesign concepts this is a controlled technical layout not a creative exercise design priorities efficient clinical workflow separation of patient flow staff service flow maximum natural light for treatment logical sterilization workflow proximity realistic and buildable door positions circulation paths room sizes compact professional dental clinic planning output format produce a complete architectural floor plan monochrome technical drawing with walls hatched where structural doors with swing windows furniture dental chairs clean readable layout matching the original drafting style exactly final instruction follow the annotated reference exactly and literally do not reinterpret do not optimize beyond instructions do not relocate zones this is a strict internal reconfiguration within a fixed architectural shell
