create a geometry only fa ade study based strictly on the reference sketch this is a cropped fragment of a continuous fa ade not the full building width the fa ade continues beyond the left and right edges do not show side walls corners end conditions or building edges no materials no textures no colors no landscape no public realm no people neutral monochrome geometry only general composition three visible structural spans column centre to centre spacing 4 5 m ground floor height 6 0 m show ground floor plus the first three levels above keep all upper levels equal in height keep the fa ade orthogonal and front facing ground floor ground floor has large corridor with glazed openings behind the columns only the upper lintel zone above the glazing remains solid ground floor columns are 1 0 m 1 0 m ground floor columns are slightly recessed behind the front lintel plane as shown in the sketch columns should not be flush with or projecting beyond the lintel main upper structure above the ground floor main vertical columns become t shaped fa ade elements the front part of each t shaped column is 500 mm deep the recessed rear part is 200 mm deep these are continuous structural elements not independent fins depth planes the fa ade has five controlled depth planes plane 1 front lintel plane most forward horizontal lintel elements plane 2 ground floor main column plane ground floor columns slightly recessed from the front lintel plane 3 recessed t shaped main column plane upper main t shaped columns two 200 mm vertical elements per span sit in this same plane plane 4 horizontal lintels above and between windows these horizontal lintels are slightly recessed from the vertical elements around the windows the recess should be subtle not deep do not push them far back plane 5 window plane windows are the deepest plane window frames sit behind the fa ade structure important alignment rules no visible side edges of the building no fa ade corners no additional bays no extra vertical fins no curtain wall reinterpretation do not change floor heights horizontal lintels must remain continuous and aligned vertical rhythm must remain constant across all spans the fa ade should read as a cropped tectonic system not a complete standalone building focus only on proportions depth hierarchy structural rhythm and fa ade geometry avoid building corners side walls visible building width landscape trees public realm paving people materials textures colors brick stone concrete finish reflections sky emphasis exaggerated recesses deep horizontal lintel recess solid ground floor walls extra fins attached mullions curtain wall changed proportions altered floor heights decorative fa ade cinematic rendering
