zaha hadid exterior shot create a clean architectural presentation sheet top a pool house floor plan 28 6 wide by 30 deep attached to the bottom wall of the pool house is a pergola structure important the pergola must keep its full original size and proportions approximately 48 wide by 36 deep do not scale or compress the pergola to match the pool house width the pergola is angled relative to the pool house and connects to only a portion of the bottom wall the pergola should extend beyond the width of the pool house naturally show structural posts beams and grid layout clearly and evenly spaced maintain accurate proportions for both structures independently use a clean black and white architectural drawing style suitable for printing no distortion no squeezing no floating elements architecture
