1 overall concept snapshot item specification name signage sells brushed aluminium channel letters on the front gable primary use community gatherings markets parties yoga classes footprint 70 ft 35 ft approx structure exposed timber frame 8 8 in rough sawn posts hidden structural steel plates roof 6 12 gable matte charcoal standing seam metal 3 ft clerestory skylight at ridgeline back wall new full height enclosure in horizontal cedar cladding clear satin finish integrates two 36 in service doors and one 10 ft glass roll up window counter height floor polished lightly stained concrete slab with saw cut control joints railing black powder coated steel tube with stainless wire infill on open sides 2 exterior rendering views 1 hero front left three quarter daylight camera height 5 ft shows open sides and back wall enclosure in one frame signage on front gable in focus include foreground path light buff concrete gently curving toward pavilion 2 direct rear elevation straight on back wall fully visible detail cedar boards 6 in reveal and roll up window partially open revealing bar counter soft landscape native grasses lavender and boulders at wall base 3 right side perspective at dusk blue hour lighting warm led up lights washing cedar wall and columns festoon string lights across front openings subtle interior glow from recessed downlights 3 interior rendering views 1 wide interior toward front openings exposed trusses matte black ceiling fans concealed conduit picnic tables powder coated steel frames composite tops arranged flexibly glimpse of open field beyond 2 service counter close up at back wall cedar back wall with roll up window open to polished concrete countertop under counter fridge farmhouse sink overhead pendant cage lights black steel 4 material texture references element texture cue finish timber posts trusses reclaimed white oak grain moderate knots clear matte sealer cedar cladding uniform 1 6 tongue and groove uv protective satin metal roofing 16 in standing seam matte charcoal ral 7016 concrete floor light grey salt and pepper aggregate low sheen sealer roll up window frame anodised aluminium dark bronze 5 lighting environment day scenes early afternoon sun 45 altitude south east azimuth crisp shadows dusk scene blue hour 15 min after sunset interior 3000 k leds 70 output exterior uplights 2700 k surroundings manicured turf a mature oak on rear right gentle rolling pasture in background distant farmhouse to tie back to original rural context 6 output checklist for renderer asset resolution notes 4 jpeg png stills 4 k 3840 2160 views listed above 1 360 panorama optional 8 k interior centre of pavilion material board pdf swatches rgb hex values layered psd exr native for post production tweaks make photoreal architecture
