convert this floor plan into a realistic isometric 3d view of a full house show the space from an elevated angle with furniture walls and details visible analyze the provided 2d architectural floor plan and generate a 3d model and interior renderings that strictly adhere to the plan dimensions and layout critical geometry instructions accurately interpret all labeled dimensions in feet and inches and maintain true scale proportions throughout the model use the dimension annotations to define wall lengths room sizes and spatial relationships maintain correct wall thickness consistency based on the plan do not approximate or redesign the layout walls structure precisely trace all walls as shown in the floor plan respect all interior and exterior wall placements identify and correctly position all openings doors including swing direction if shown windows do not add remove or shift walls room definitions maintain exact room boundaries bedroom living room kitchen bathroom hallways and closets preserve circulation paths and clearances ceiling height assumptions use standard ceiling height of 8 9 ft unless otherwise specified keep proportions realistic relative to room dimensions interpretation rules if any dimensions are unclear prioritize proportional relationships from the plan do not invent additional architectural features do not modify layout for aesthetics rendering style generate isometric or perspective views that clearly show the full layout use clean minimal materials to highlight geometry accuracy avoid excessive decoration that could obscure spatial accuracy furniture secondary priority add minimal properly scaled furniture only after layout is accurately constructed ensure furniture does not distort perceived room size goal produce a geometrically accurate 3d representation of the floor plan that can be used for architectural validation and client presentation validation step before generating final images internally verify room dimensions match labeled measurements wall alignments are consistent across all connected spaces door and window placements align with plan annotations if inconsistencies are detected correct them before rendering after geometry is validated apply interior design style modern mountain with warm wood tones soft white walls matte black accents and minimal furniture use the same furniture as shows on the plan do not change the orientation of the floorplan
