create a photorealistic virtual staging concept for an internal mezzanine upgrade at bodicomplete gym kirrawee nsw australia showing a new fully clad balustrade joinery solution installed between the existing red steel columns design intent the current balustrade is being upgraded because the existing condition is not suitable for public use the new design must read as a complete replacement full cladding solution so that no existing balustrade is visible or visually functional the outcome should look suitable for a local council approval presentation while still being realistic for a simple budget and manufacturable by a joinery shop using cnc machining architectural setting existing industrial gym interior exposed insulated metal roof sheeting red painted steel portal frame columns and beams white light wall surfaces behind mezzanine view from gym floor looking up to mezzanine edge retain the real building proportions and span between steel columns keep the overall warehouse fitness environment authentic not luxury retail balustrade design requirements entire mezzanine balustrade face is to be fully clad in manufactured joinery panelling no perforated metal mesh exposed rail infill or visually open balustrade sections no part of the old balustrade should be seen through above or below the new joinery skin use a modular panel system suited to cnc manufacture panels should look like economical joinery construction using sheet material not custom metal fabrication use clean repeated modules practical joints and realistic panel sizes for manufacture and installation minimal material palette emphasis on flat panel routing engraving rebating rather than multiple applied components budget conscious detailing joinery should appear durable and appropriate for a gym environment material and finish direction matte black or dark charcoal joinery finish cnc routed panel detailing only subtle engraved or recessed branding slogans optional shallow routed linework or geometric scoring for visual relief no expensive mixed materials no perforated steel look no decorative metal screens no highly glossy finishes no timber veneer unless very subtle and secondary graphic branding direction use large scale simple bold integrated graphics that can be cnc routed into the panel faces keep it architectural and restrained not like stick on signage possible text placement across selected panels show up train with intent move well stronger for life built in kirrawee kirrawee use only 2 or 3 slogan zones maximum so the design remains clean and credible form and composition full height solid panelled balustrade between steel columns strong horizontal datum repeated modular bays one or two feature panels with engraved slogans one quieter panel for logo local identity wayfinding conceal the previous rail logic completely keep the design visually robust simple and compliant looking avoid climbable expression avoid transparent or open elements make the balustrade read as a solid safe architectural edge manufacturing realism show believable cnc joinery construction panel joints aligned logically realistic shadow gaps or expressed vertical joints practical end conditions at steel posts realistic tolerance to existing structure looks installable by a commercial joinery fitout contractor low complexity design suitable for shop drawings and production output image style highly photorealistic real world lighting accurate perspective from the gym floor keep existing building shell recognisable present as a realistic design proposal not a fantasy render suitable for client design approval
