master closet the image provided is a detailed elevation drawing for a custom closet or cabinetry system it outlines the dimensions materials and specialized lighting features for a radiant white storage unit dimensions and layout the system is divided into four main vertical sections total width approximately consisting of three sections and a larger end unit total height roughly section breakdown left and right sections feature pull down hanging rails for pants and adjustable shelving center section includes a belt rack and a dedicated area for dresses standing tall far right section a large wood frame unit intended for a glass insert lighting and electrical the plan specifies several integrated led systems for a high end finish vertical lighting blade led linear lights in cool white are recessed into the vertical partitions accent lighting includes provisions for led toe kick lighting and inside cabinet lighting controls electrical outlets eo are noted for cabinet lighting dimmers and switches material specifications finish most components are specified in radiant white depth the standard shelf and cabinet depth is noted as hardware includes specialized pull down hanging rails to maximize vertical space
