zaha hadid exterior shot realistic 3d floor plan layout of the main floor of a single family home 988 sq ft living space the layout includes the following rooms and spaces great room 12 0 x 14 4 open to above located centrally with staircase adjacent dining room 14 0 x 9 6 open to the kitchen with an engineered flush beam above kitchen 11 4 x 11 4 includes island refrigerator and pantry alcove adjacent to dining pantry off the kitchen on the east side den flex room 10 10 x 9 0 located near the front entry can serve as office or bedroom mudroom near the rear garage entry with closet and bench area 2 piece bathroom near the mudroom den area coat closet near main entry covered deck approx 12 0 x 10 0 accessible from the dining area via sliding door triple attached garage 34 0 wide non rectangular footprint with the left two stall side being 23 0 deep and the right single stall side being 26 6 deep creating a stepped rear wall two overhead doors one 18 x9 double wide door on the left covering two stalls and one 8 x9 single door on the right for the third stall finished interior with insulated walls and ceiling 12 7mm gypsum board with vapour barrier engineered raised beam across the garage opening general notes open concept main living area 9 foot ceilings throughout wood look flooring in main living areas central staircase leading to upper floor garage entry connects to mudroom architecture
