architectural fa ade detail cross section of the same building following the exact crop shown in the reference image show realistic layered construction reinforced concrete interior slab 300 mm thick and exterior projecting slab 500 mm thick supported by rounded polished beige pigmented concrete column curved green olive grc sandwich fa ade panel with integrated eps insulation and interior drywall layer flush with the interior face of the brass window frame mechanical fixing brackets connecting panel to concrete structure continuous waterproofing and thermal break at slab edge burnished antique brass window profiles with concealed hinges and double glazing concrete column meets directly the brass jamb with no metal cover interior suspended gypsum false ceiling aligned precisely with the top of the brass window profile finished with clay plaster interior floor build up 200 mm thick including acoustic insulation screed and beige limestone tiles 800 800 30 mm material quality polished beige concrete with visible mineral aggregate green olive grc rough brush hammered texture warm satin burnished brass insulation clearly visible in section style ultra realistic construction detail section sharp edges accurate layers neutral background avoid artistic lighting stylization exploded views simplified diagrams soft focus or material changes
