1 base model from uploaded floor plan use the uploaded 2d architectural floor plan as the exact footprint and room layout key constraints total building size approximately 1 576 sq ft single storey modern coastal house building footprint forms an l shaped composition long wing oriented toward ocean views secondary wing contains private bedroom zone spaces in the drawing correspond to a entrance b kitchen c pantry laundry d living room e terrace deck f powder room g covered terrace h bedroom i bathroom j storage k primary bedroom use the drawing proportions and scale bar to determine wall lengths and geometry 2 building massing the house should be modeled as single storey structure flat roof with slight hidden slope for drainage modern minimalist coastal architecture approximate heights exterior wall height 9 ft interior ceiling height 9 10 ft roof thickness 12 16 inches the building consists of two rectangular volumes joined at an angle forming an l the longer volume contains kitchen dining living room the shorter volume contains bedrooms bathrooms 3 exterior architectural style render the building to match the provided reference images architectural style contemporary coastal modern key characteristics clean horizontal geometry simple rectangular massing minimal ornamentation emphasis on views and glazing exterior materials primary siding horizontal cedar cladding natural weathered grey tone narrow boards roof flat membrane roof dark charcoal color concealed drainage window frames black aluminum slim profiles 4 windows and glazing ocean facing elevation should include full height glazing panels large sliding glass doors opening to the terrace glass characteristics floor to ceiling black aluminum frames modern minimal mullions window heights approx 7 8 ft tall bedroom wing should have fewer windows medium rectangular windows 5 deck terrace the floor plan identifies e terrace and g covered terrace model this as large exterior deck running along the ocean facing facade characteristics natural wood decking flush with interior floor elevation extends 8 10 ft outward covered terrace recessed space within building volume same roof plane above 6 site context place the building within a coastal pei landscape site characteristics grassy coastal field low shrubs and grasses gently sloping land toward ocean distant water horizon orientation main glazing faces north northeast toward ocean road access behind the house include coastal grasses minimal landscaping no urban elements 7 interior style interior design style minimal scandinavian coastal features light wood flooring white walls natural wood furniture simple modern furnishings living room lounge chairs sofa low modern table oriented toward ocean view kitchen modern island minimalist cabinetry light wood white palette 8 rendering instructions generate 3d massing model fully textured architectural render exterior views from multiple angles interior view toward ocean axonometric schematic section perspective site context rendering camera angles aerial view terrace perspective ocean facing elevation living room interior view lighting soft coastal daylight slightly overcast sky typical of atlantic canada 9 model accuracy priority prioritize exact footprint from floor plan correct l shaped geometry deck placement window placement matching reference images horizontal cedar cladding 10 final output produce realistic 3d architectural renderings schematic architectural diagrams massing study exterior and interior perspective views the result should visually match a modern pei coastal house similar to the reference images
