you are an architectural renderer use the uploaded reference image as the primary reference for proportions grading and facade composition produce a set of clean developer style renderings and annotated elevations that precisely communicate the design intent below project context use for environment lighting and site treatment location iqaluit nunavut high arctic far north canada show tundra rocky slope light snow cover where appropriate sparse vegetation site steep hill side elevations show a substantial drop toward the rear emphasize the slope in perspective and both side elevations lighting cool daylight with a low sun angle long but soft shadows typical of high latitude overcast variant acceptable for clarity keep overall lighting neutral and realistic avoid warm california sunlight hard constraints and dimensions must be respected building two story total height 23 ft rear grading drops substantially there are exactly 21 steps from the rear parking lot up to the rear exit door show riser run visually and annotate count bottom underbuilding x pattern hatch on rear elevation wire mesh closing the bottom of the building show as x hatch wire mesh material mechanical room located on the right side of the rear elevation below the building floor of that mechanical room is approximately 12 ft lower than the main floor show vertical offset and door access diagonal element on front and east elevations the diagonal line connecting to a box three wood columns skewed from the roof that support characterize the projecting roof box show their skew spacing and connection to the overhang accurately this feature is critical include a close up detail view soffits wood soffits on overhangs show wood grain tone consistent with other wood elements in close up windows aluminum curtain wall style black frames clear glass horizontal siding appears between curtain wall window bands maintain that rhythm proportions use the uploaded elevations for proportions where ambiguous maintain the visual relationships from the images floor heights window heights roof overhang materials finishes and colors strict flat panels smooth finish kingspan panels used as accent panels show subtle revealed joints finish color stainless steel metallic neutral no saturated color siding westman steel corrugated panels for both vertical and horizontal siding lines show corrugation profile and transitions between vertical and horizontal runs primary palette stainless steel metallic natural wood warm medium tone flat panels may be the accent metallic while siding mixes steel and wood do not use blue or red mesh wire mesh with x pattern as drawn in rear elevation window frames black glass clear low reflectivity for clarity fasteners joints show realistic shadowing and seams typical of kingspan and corrugated steel required views and deliverables front perspective preferred camera 28 35 mm focal length equivalent the skewed wood columns and roof overhang developer rendering style crisp lines subtle realistic materials moderate environmental context snow rock front elevation orthographic annotated with overall building height 23 ft material callouts and the diagonal box three column detail rear elevation orthographic annotated to show the 21 exterior steps from parking to exit the x pattern mesh enclosure at the base and the mechanical room location both side elevations orthographic show grading line and how the ground drops off annotate the mechanical floor being 12 ft lower than main floor on the right side elevation show foundation underbuilding clearance as in the reference detail close up s skewed wood columns and connection to roof box kingspan flat panel seam and westman corrugated joint curtain wall window horizontal siding junction wire mesh hatch detail material callout sheet 1 page legend keyed to elevations panel type and finish siding type orientation wood species finish suggestion mesh type window frame color rendering style and presentation style developer architectural visualization clear precise slightly stylized realism not hyperphotoreal use crisp line definition true material textures subtle ground context and readable annotations colors neutral cool environment building palette constrained to stainless metallic wood no blue red accents output files png or tiff renders 3840 2160 min for perspective 300 dpi vector pdf or high resolution png for elevations and annotated sheets provide two quick material variation options same composition 1 wood dominant warmer wood emphasis with metal accents 2 metal dominant stainless look with wood accents both must respect all constraints above instructions for using the uploaded reference images use the four uploaded images front rear and both sides to match window placements roof line and the relationship of openings to floor levels maintain the locations and alignment shown preserve the diagonal box three column element exactly as drawn if necessary request clarification before deviating use the side elevations to set the terrain slope and the rear elevation to position the steps and mesh hatch precisely if proportions are ambiguous follow the apparent scale in the reference images and retain the specified measurements 23 ft total height 21 steps mechanical floor 12 ft lower deliverable checklist to return high res corner perspective png two material variations front elevation annotated png pdf rear elevation annotated png pdf showing 21 steps and mesh hatch left and right side elevations annotated png pdf showing grading and mechanical room offset 2 3 close up detail renders columns panel joint curtain wall one page material legend and short notes pdf tone for labels annotations use simple clear annotation language e g kingspan smooth flat panel stainless tone westman corrugated steel horizontal wire mesh x hatch 21 steps to parking mech room floor 12 ft below main strict dos and don ts do show the steep slope 21 steps wire mesh hatch mechanical room floor offset and skewed wood columns accurately do keep window frames black and glass clear do use kingspan flat panels and westman corrugated steel appearance for the correct material texture look don t introduce blue or red as primary accent colors don t change the three column diagonal box element or obscure it don t omit the mechanical room offset or miscount the steps if any element in the uploaded references is unclear exact column angles proportion of 21 steps vs landing width exact location of mechanical room access ask for clarification or mark a note in the annotated elevations indicating assumed dimensions so they can be reviewed
