cad ref important a cad elevation drawing is attached as a reference image reproduce the layout exactly as shown positions proportions and heights exact module widths left to right total 3300mm 1 600mm tall full height column left side integrated fridge freezer floor to ceiling 2 600mm base cabinet sink unit with tap above worktop 3 450mm base cabinet integrated dishwasher panel fronted 4 450mm base cabinet 5 burner gas hob set into worktop 5 600mm base cabinet standard no appliance 6 600mm tall full height column right side oven lower microwave upper floor to ceiling ceiling mounted hood suspended above modules 4 5 450 600mm zone 1050mm total span hanging on rods cables from ceiling directly above the hob hood body width approximately 900mm centred over the hob do not alter these widths or positions the proportions in the cad drawing are the ground truth for this render intro create a photorealistic architectural visualization of a modern kitchen run wall kitchen no island front elevation view matching the attached cad drawing full width visible total width 3300mm contemporary scandinavian style warm refined high quality interior photography with soft natural daylight from the left and warm ceiling spotlights camera straight front or max 15 angle aspect ratio 16 9 kolory lower base cabinets modules 2 5 kronospan k697 cocoa primavera oak very dark smoked oak near charcoal espresso brown strong vertical grain synchronized embossing texture very dark not medium brown upper wall cabinets kronospan k7166 latt feelness ultramatt completely flat ultra matte warm taupe brown zero sheen smooth no grain tall columns modules 1 and 6 k697 cocoa primavera oak same dark oak as base cabinets full height plinth kickboard bottom of base cabinets kronospan al06 brushed bronze warm champagne bronze fine horizontal brush lines metallic blat worktop runs across modules 2 5 only base cabinets 2250mm total tall columns have no worktop option a taj mahal quartzite creamy warm white soft golden amber veining matte low sheen option b calacatta macchia vecchia white bold grey and gold veining dramatic matte preferred thickness 20mm straight eased edge detale handles h fele barchester bar pull 160mm centre antique bronze aged warm dark bronze slightly patinated on all cabinet doors and drawers including tall columns tap antique bronze pull out warm aged dark bronze matching handles agd module 1 600mm tall left column siemens 70 30 integrated fridge freezer full floor to ceiling height module 2 600mm base schock asus 04 undermount sink dark anthracite composite granite in stone worktop antique bronze pull out tap above module 3 450mm base siemens integrated dishwasher panel front in k697 cocoa primavera oak module 4 450mm base siemens iq500 ep9a6mi40n 5 burner gas hob stainless steel with cast iron pan supports set flush into stone worktop module 5 600mm base standard base cabinet no appliance module 6 600mm tall right column siemens iq700 bf722r1b1 microwave upper position siemens built in oven lower position full floor to ceiling height ceiling hood above modules 4 5 siemens iq300 lc87kfn60 island type ceiling extraction hood suspended on rods from ceiling stainless steel and glass centred over modules 4 5 hob adjacent base cabinet hood body approx 900mm wide render photorealistic high resolution interior photography soft daylight from left warm ceiling spots realistic textures deep grain on dark oak fronts flat matte on latt upper cabinets brushed metallic plinth stone veining on worktop aged bronze patina on handles and tap white light plaster walls light oak or herringbone parquet floor no people minimal styling only small plant cutting board no clutter on worktop
