strict architectural geometry transfer left access ramp you are provided with two images image 1 the existing photorealistic rendering image 2 the original archicad architectural model your task is to correct the left access ramp and its associated railing system in image 1 by accurately transferring the architectural geometry from image 2 critical the archicad model is the definitive geometric authority for the entire left ramp do not use the existing ramp geometry in the rendering as a guide the ramp in the rendering is geometrically incorrect and must be replaced by the ramp configuration shown in the archicad model this is not an approximate adjustment creative interpretation or aesthetic redesign 1 exact ramp geometry study the ramp in the archicad model carefully reconstruct its actual three dimensional spatial configuration in the rendering transfer the following geometric properties directly from the model exact ramp starting position at the lower garage forecourt level exact ramp endpoint at the elevated terrace level overall ramp length ramp width ramp inclination and longitudinal slope direction of travel position of both longitudinal ramp edges connection to the lower ground level connection to the upper terrace geometry and height development of the adjacent retaining wall the lower starting point and upper endpoint must correspond to the archicad reference the ramp must rise continuously from the lower garage forecourt to the elevated terrace following the exact spatial configuration shown in the model do not retain the existing ramp shape simply because it is already present in the rendering it is incorrect do not shorten lengthen widen narrow reposition or change the inclination of the ramp beyond what is required to reproduce the archicad reference preserve the specific geometric relationships between the ramp the garage forecourt the retaining wall and the elevated terrace 2 exact left side railing geometry the entire railing system associated with the left ramp must follow the archicad model reproduce the actual railing configuration including the location of each railing section the distinction between horizontal terrace railings and inclined ramp railings their respective heights their respective slopes the alignment of posts the length of individual railing sections the exact transitions between inclined and horizontal sections the relationship between railings and adjacent walking surfaces pay particular attention to the fact that the ramp railing and the horizontal terrace railing follow different geometric paths do not merge separate railing sections into one continuous invented arrangement do not invent additional handrails posts horizontal bars or railing connections the archicad model defines the correct railing configuration preserve the existing black metal material and slender profile appearance from the rendering 3 absolutely protected staircase the entire staircase and its railings are completely locked this is the one area where the archicad model must not be followed the staircase geometry in the archicad model is outdated the photorealistic rendering contains the correct staircase including its curved and widening geometry preserve exactly every staircase step the curved and widening staircase layout the staircase orientation the staircase width and height both staircase side walls both curved staircase railings all existing staircase railing posts the staircase handrail geometry both planters the connection to the garden path no part of the staircase may be modified do not transfer the straight staircase from the archicad model do not change the staircase railing while correcting the adjacent ramp railing where the ramp system approaches the staircase adapt only the editable ramp side geometry to meet the existing completely unchanged staircase area 4 reference priority no ambiguity the two reference images have different responsibilities archicad model absolute authority for left ramp geometry left ramp length left ramp slope left ramp position left ramp retaining wall geometry left side ramp railing horizontal railing sections associated with the left terrace photorealistic rendering absolute authority for entire staircase and its curved railings all architecture outside the ramp editing area camera position and perspective building proportions existing materials lighting and atmosphere vegetation and furniture when the ramp geometry differs between the two images always follow the archicad model when the staircase geometry differs between the two images always follow the photorealistic rendering do not compromise between the two geometries 5 accurate perspective transfer the archicad screenshot and the photorealistic rendering show the architecture from slightly different viewpoints account for this difference in camera perspective when transferring the ramp geometry reconstruct the ramp in three dimensional space according to the archicad model then depict it from the existing camera viewpoint of the rendering do not simply copy two dimensional lines from the archicad screenshot do not rotate move or reframe the camera to make the geometry fit the building and staircase must remain exactly where they are 6 preservation of all other elements outside the editable left ramp and railing area do not change any geometry keep the house garage windows roof staircase right terrace right railings bench planting garden path ground materials lighting and atmosphere unchanged do not modify any architectural height or level outside the left ramp correction area do not introduce additional architectural elements final requirement the final result must preserve the existing photorealistic rendering while replacing the incorrect left ramp configuration with the actual ramp geometry from the archicad model the ramp must match the reference in its spatial form length slope position and railing arrangement geometric accuracy is more important than preserving the existing incorrect ramp the staircase and its curved railing must remain absolutely identical to the original rendering no creative interpretation no approximateuse the provided photorealistic rendering as the base image use the provided archicad model only as a reference for the railing geometry this is a strict railing only edit only correct the railing do not change anything else in the image absolute rule treat the entire image as locked except for the railing only the railing system may be edited do not modify ramp geometry staircase geometry terrace geometry retaining walls wall heights wall edges house garage garden path paving bench planters planting furniture lighting camera perspective framing materials do not change any levels slopes planes or dimensions this is not an architectural redesign this is not a ramp correction this is not a terrace correction this is only a railing correction what the archicad model is used for use the archicad model only to understand the railing layout the railing course the railing heights the distinction between horizontal and sloping railing sections the transitions between railing segments the relative position of posts and railing runs the archicad model is only a railing reference do not transfer any other geometry from it locked staircase zone the staircase and the railing directly belonging to the staircase must remain exactly as they are in the rendering do not change the curved staircase railing the handrails along the staircase the railing posts at the staircase the transition immediately attached to the staircase if it would alter the existing staircase railing geometry important the staircase zone is protected do not straighten it do not reinterpret it do not adopt the straight staircase logic from the archicad model editable railing zones only edit the railing outside the protected staircase zone especially the railing along the left ramp the horizontal railing section on the left terrace the connection between the sloping ramp railing and the horizontal left terrace railing if necessary also refine the railing continuity on the right side only if this can be done without altering the staircase railing terrace geometry or any other architectural element railing correction goal correct the railing so that its geometry follows the logic shown in the archicad model focus on correct railing height correct railing slope along the ramp correct alignment of horizontal railing sections correct position and spacing of posts correct distinction between sloping and horizontal railing runs correct transitions between segments clean and believable railing continuity do not invent extra railing segments do not add additional bars or handrails do not merge separate railing sections incorrectly do not create a new railing design visual appearance keep the existing black metal railing appearance from the rendering same material same color same slender metal profile same photorealistic style do not redesign the railing aesthetically only correct its geometry and course final requirement the final image must remain identical to the input rendering in every respect except for the railing the only visible changes allowed are corrections to the railing geometry outside the protected staircase zone nothing else may change in short edit only the railing use the archicad model only as railing reference keep the staircase and its railing unchanged do not change ramp terrace walls materials or any other geometry geometry no architectural redesign
