make guyana airbnb house with this description lot 161 two story self contained residence airbnb ready diagram outline for architect updated with utility sustainability considerations overall footprint 60 ft e w 89 ft n s 5 380 sq ft per floor corridor 8 ft wide running north south stairs one enclosed stair at north end one at south end bedrooms 12 total 6 per floor grouped into 4 lockable blocks a d of 3 rooms each ground floor layout self contained with utilities zoning north block a 3 bedrooms self contained share corridor section a lockable door between block a and main corridor south block b 3 bedrooms self contained share corridor section b lockable door between block b and main corridor central service core between a b living room 400 480 sq ft kitchen pantry 300 340 sq ft powder room 30 sq ft laundry 120 sq ft storage 120 sq ft electrical room 150 sq ft enlarged for inverters solar controls and main panels pump room 80 sq ft janitor mop 25 sq ft circulation lobby 450 500 sq ft external adjacent elements rear utility zone water tanks six 6 1 000 gallon tanks 6 7 ft dia 300 sq ft total mounted on a reinforced platform with access for maintenance generator 100 kva diesel generator 8 ft 4 ft pad 32 sq ft housed in sound insulated enclosure positioned near tanks with sufficient ventilation and exhaust clearance guard hut with bathroom 120 sq ft lock off logic ground floor block a and block b separated by rated lock off doors each block can access or be isolated from the living kitchen area possible configurations 3 bed a or b 6 bed a b airbnbs upper floor layout self contained zoning north block c 3 bedrooms with lock off access to corridor c south block d 3 bedrooms with lock off access to corridor d central shared spaces living room 360 420 sq ft kitchen pantry 260 300 sq ft linen housekeeping closet 50 sq ft circulation lobby 450 500 sq ft lock off logic upper floor block c and d separated by rated lock off doors each block can access or be isolated from upper kitchen living whole floor can be locked off from main stairs lobby for independent rental possible configurations 3 6 9 or 12 bed setups by combining a b c d mep structural coordination notes electrical two main meters one per floor four subpanels one per 3 room block a b c d enlarged electrical room 150 sq ft for inverters battery storage solar controllers and generator transfer 1systems dedicated vertical electrical chase from roof to electrical room for clean routing of solar cables and ac feeds generator backup for life safety essential loads solar integration roof designed for maximum solar exposure from 9 00 am 2 00 pm orientation slant roofs toward the west to optimize solar panel conductivity since sunlight travels east to west use low slope or mono pitch roof design conducive to photovoltaic array installation provide sufficient roof access and cable conduits tied to the central chase water pump system six 1 000 gallon tanks at rear on raised platform with interconnection and overflow protection pump room connected directly to tanks for pressure maintenance water supply to each floor zoned and valved separately hvac split inverter type ac units in all bedrooms and shared spaces living kitchens laundry if required outdoor ac condensers consolidated on one service ledge preferably rear fa ade for easy maintenance and drainage structural design to accommodate condenser loads and ensure noise separation from rooms fire life safety two enclosed stair cores north south 8 ft corridor with emergency lighting 1 hour rated lock off doors between room blocks elevation roof massing intent clean symmetrical two story form flat or low pitch roof slanted westward to maximize solar efficiency option for parapet with hidden gutters balcony or fa ade relief on north south ends optional external ac ledge and tank generator area screened with architectural fencing deliverables requested from architect updated floor plans showing rear utility yard with tanks and generator electrical riser showing solar conduit path and inverter room layout roof plan detailing solar panel layout and slope direction hvac plan showing consolidated condenser ledge and refrigerant line routes plumbing plan with expanded tank and pump connections structural layout for tank pad and generator slab all previous architectural structural electrical and plumbing deliverables updated accordingly design intent summary create a 12 key two story residence where each floor operates independently with added infrastructure for a six tank water system 100 kva generator and solar ready roofing slanted westward for optimal 9 am 2 pm exposure the electrical room must accommodate inverters and batteries with a dedicated chase 1 2 3 4 5 6 7 2for clean solar cable routing hvac condensers to be grouped on a shared ledge for simplified service and improved aesthetics 3 make me proposer plan
