create a fully buildable architectural masterplan for a residential development on a rectangular parcel measuring 22 meters width x 160 meters length total area approx 3 520 m site geometry access critical the parcel is long and narrow width 22m fixed length 160m the only access point is located on the right side of the parcel positioned at the upper corner of the 22m side entrance width 4 meters this access must be used as the primary vehicular entry into the development internal circulation strategy mandatory design a functional internal road system starting from the 4m entrance road width 4 meters minimum the road must enter from the upper right corner continue longitudinally along the parcel be optimized to serve all 8 units preferred solutions option a recommended linear road along one side right or center option b slight l shape or branching if needed for better access include turning radius or maneuvering pocket at the end avoid dead end without turning solution plot subdivision logic very important you must divide the land into 8 buildable residential plots suggested modular logic total length 160m divide into 8 segments 20m depth each each unit plot depth 18 22m plot width variable depending on road placement width strategy since total width is 22m scenario 1 most realistic 4m internal road one side remaining 18m for housing zone houses width 7 8m each paired or single loaded scenario 2 central road 4m houses on both sides tight but possible 8 9m per side including setbacks choose the most efficient and realistic configuration house planning criteria each of the 8 houses must include typology modern townhouse or compact villa floors ground floor 1 g 1 footprint 70 100 m total built area 140 200 m functional requirements per unit 1 parking space outdoor or integrated private entrance small rear or front yard natural light from at least 2 sides if possible setbacks spacing minimum side setbacks 1 1 5m if applicable front setback towards road 3 5m rear yard min 4 6m preferred ensure privacy between units no unrealistic tight spacing landscape site quality integrate green strips between units or along road trees along internal road optional pedestrian path clean and organized outdoor spaces deliverable requirements produce 1 2d masterplan mandatory exact parcel outline 22m x 160m entrance location clearly marked upper right internal road layout 4m width all 8 houses positioned precisely plot divisions with approximate dimensions 2 functional diagram circulation arrows access to each unit parking positions 3 optional simple 3d massing clean volumes basic landscape visualization strict constraints do not exceed parcel boundaries do not invent new access points must use the exact entrance position upper right 4m must fit exactly 8 units not more not less must be realistic and buildable design intent the final result should feel like a real small residential compound efficient investor ready layout optimized for maximum land use livability suitable for kosovo european residential standards final instruction important prioritize efficiency of land use clear circulation buildable geometry clean architectural logic avoid conceptual abstract layouts unrealistic spacing overdesigned or decorative plans
