architectural fa ade detail cross section of the same building shown in the reference image tightly cropped at slab edge curved fa ade panel window jamb and interior ceiling show realistic layered construction with the following systems structure reinforced concrete slab 300 mm thick interior exterior projecting reinforced concrete slab 500 mm thick rounded polished beige pigmented concrete column supporting slab fa ade system curved green olive grc sandwich panel as exterior cladding eps thermal insulation integrated within the panel build up interior drywall layer flush with the interior face of the brass window frame concealed mechanical fixing brackets connecting grc panel back to concrete structure continuous thermal break and waterproofing membrane at slab edge window system burnished antique brass window profiles with concealed hinges double glazing seated into brass frame with clean tight tolerances concrete column meeting directly the brass jamb no vertical metal cover interior finishes standard suspended false ceiling system gypsum boards on metal stud grid clay plaster finish to ceiling surface ceiling aligned precisely with top edge of brass window profile floor build up 200 mm total floor build up including acoustic insulation layer cement screed beige limestone tiles 800 800 30 mm as final finish material quality beige concrete polished mineral aggregate visible green olive grc rough brush hammered texture brass warm satin burnished patina insulation clearly legible in section style ultra realistic architectural construction section sharp edges accurate layering neutral background no cinematic lighting no artistic effect no color grading change avoid artistic rendering exploded axonometric simplified diagram mood lighting conceptual sketch exaggerated shadows fantasy construction changed materials soft focus blurry edges stylized textures
